Mono paper refers to a quality consisting of only one layer. It is usually a specially surface-treated paper for advertising purposes such as high-quality brochures or for thermal transfer printing, which is often used in the logistics sector.

However, mono paper can also be a commercially available, wood-free office paper or a film, such as polypropylene (PP) or polyethylene (PE), if special properties such as tear resistance or water resistance are required.

Incidentally, thermal and wax papers can also be considered mono papers, provided they have not been further processed into laminate or composite goods.

Our mono papers for the advertising and logistics sector are characterized by excellent printability in conventional printing processes such as flexo, offset, inkjet or TTF (thermal transfer printing). They have a special coating and surface treatment, which have a silky-matt or even extra-smooth and glossy character. Silky matte coated papers, which exhibit a semi-gloss and also have a high degree of whiteness, are becoming increasingly popular. The increased contrast due to the bright, white coating combined with the homogeneous surface ensures high-quality products, as they deliver brilliant print results.

But also in logistics, our mono materials offer corresponding quality features that meet the high demands of industrial applications. With the ever-increasing throughput volumes here, impeccable and thus trouble-free readability of the printing, such as barcodes or QR codes, must continue to be guaranteed. Excellent runnability during further processing thus becomes even more important than it already is. This is achieved not least because of the base materials used here with their very special physical properties.

You can obtain the following monopapers from us:

Thermotransfer

BluTag Transfer TTF 115 NL

BluTag Transfer TTF 115 NL

Product characteristics

  • Woodfree bright white coated paper
  • Softwood and hardwood pulp
  • Soft calendered, silk matt and extra smooth

Physical properties

Physical properties Typical value Unit Norm
Basis weight 115 g/m² ISO 536
Thickness 98 µm ISO 534
Smoothness (PPS 10) 2,0 µm ISO 8791-4
Volume 0,85 cm³/g ISO 534
Whiteness D65 99 % ISO 2470-2
CIE whiteness 125 % -
Gloss (Hunter) 40 % ISO 8254-1
Gloss (Lehmann) 45 % ISO 8254-2
Opacity 94 % ISO 8791-4

General information

The product data listed represent average values and describe the current quality status. They do not constitute a guarantee of specific properties for a specific application. Before using the product, we recommend carrying out suitable print and application tests. The paper should be stored at a constant temperature of 23 ± 5 °C and relative humidity of 50 ± 10 %.

BluTag Transfer TTF 130 NL

BluTag Transfer TTF 130 NL

Product characteristics

  • Woodfree bright white coated paper
  • Softwood and hardwood pulp
  • Soft calendered, silk matt and extra smooth

Physical properties

Physical properties Typical value Unit Norm
Basis weight 130 g/m² ISO 536
Thickness 111 µm ISO 534
Smoothness (PPS 10) 2,0 µm ISO 8791-4
Volume 0,85 cm³/g ISO 534
Whiteness D65 99 % ISO 2470-2
CIE whiteness 125 % -
Gloss (Hunter) 45 % ISO 8254-1
Gloss (Lehmann) 50 % ISO 8254-2
Opacity 95 % ISO 8791-4

General information

The product data listed represent average values and describe the current quality status. They do not constitute a guarantee of specific properties for a specific application. Before using the product, we recommend carrying out suitable print and application tests. The paper should be stored at a constant temperature of 23 ± 5 °C and relative humidity of 50 ± 10 %.

BluTag Transfer TTF 150 NL

BluTag Transfer TTF 150 NL

Product characteristics

  • Woodfree bright white coated paper
  • Softwood and hardwood pulp
  • Soft calendered, silk matt and extra smooth

Physical properties

Physical properties Typical value Unit Norm
Basis weight 150 g/m² ISO 536
Thickness 134 µm ISO 534
Smoothness (PPS 10) 2,0 µm ISO 8791-4
Volume 0,89 cm³/g ISO 534
Whiteness D65 99 % ISO 2470-2
CIE whiteness 125 % -
Gloss (Hunter) 45 % ISO 8254-1
Gloss (Lehmann) 50 % ISO 8254-2
Opacity 97 % ISO 8791-4

General information

The product data listed represent average values and describe the current quality status. They do not constitute a guarantee of specific properties for a specific application. Before using the product, we recommend carrying out suitable print and application tests. The paper should be stored at a constant temperature of 23 ± 5 °C and relative humidity of 50 ± 10 %.

BluTag Transfer TTF 170 NL

BluTag Transfer TTF 170 NL

Product characteristics

  • Woodfree bright white coated paper
  • Softwood and hardwood pulp
  • Soft calendered, silk matt and extra smooth

Physical properties

Physical properties Typical value Unit Norm
Basis weight 170 g/m² ISO 536
Thickness 158 µm ISO 534
Smoothness (PPS 10) 2,0 µm ISO 8791-4
Volume 0,93 cm³/g ISO 534
Whiteness D65 99 % ISO 2470-2
CIE whiteness 125 % -
Gloss (Hunter) 50 % ISO 8254-1
Gloss (Lehmann) 50 % ISO 8254-2
Opacity 98 % ISO 8791-4

General information

The product data listed represent average values and describe the current quality status. They do not constitute a guarantee of specific properties for a specific application. Before using the product, we recommend carrying out suitable print and application tests. The paper should be stored at a constant temperature of 23 ± 5 °C and relative humidity of 50 ± 10 %.

BluTag Transfer TTF 200 NL

BluTag Transfer TTF 200 NL

Product characteristics

  • Woodfree bright white coated paper
  • Softwood and hardwood pulp
  • Soft calendered, silk matt and extra smooth

Physical properties

Physical properties Typical value Unit Norm
Basis weight 200 g/m² ISO 536
Thickness 186 µm ISO 534
Smoothness (PPS 10) 2,0 µm ISO 8791-4
Volume 0,93 cm³/g ISO 534
Whiteness D65 99 % ISO 2470-2
CIE whiteness 125 % -
Gloss (Hunter) 50 % ISO 8254-1
Gloss (Lehmann) 50 % ISO 8254-2
Opacity 99 % ISO 8791-4

General information

The product data listed represent average values and describe the current quality status. They do not constitute a guarantee of specific properties for a specific application. Before using the product, we recommend carrying out suitable print and application tests. The paper should be stored at a constant temperature of 23 ± 5 °C and relative humidity of 50 ± 10 %.

BluTag Transfer TTF 250 NL

BluTag Transfer TTF 250 NL

Product characteristics

  • Woodfree bright white coated paper
  • Softwood and hardwood pulp
  • Soft calendered, silk matt and extra smooth

Physical properties

Physical properties Typical value Unit Norm
Basis weight 250 g/m² ISO 536
Thickness 232 µm ISO 534
Smoothness (PPS 10) 2,0 µm ISO 8791-4
Volume 0,93 cm³/g ISO 534
Whiteness D65 99 % ISO 2470-2
CIE whiteness 125 % -
Gloss (Hunter) 50 % ISO 8254-1
Gloss (Lehmann) 50 % ISO 8254-2
Opacity 99,5 % ISO 8791-4

General information

The product data listed represent average values and describe the current quality status. They do not constitute a guarantee of specific properties for a specific application. Before using the product, we recommend carrying out suitable print and application tests. The paper should be stored at a constant temperature of 23 ± 5 °C and relative humidity of 50 ± 10 %.

BluTag Transfer TTF 300 NL

BluTag Transfer TTF 300 NL

Product characteristics

  • Woodfree bright white coated paper
  • Softwood and hardwood pulp
  • Soft calendered, silk matt and extra smooth

Physical properties

Physical properties Typical value Unit Norm
Basis weight 300 g/m² ISO 536
Thickness 290 µm ISO 534
Smoothness (PPS 10) 2,0 µm ISO 8791-4
Volume 0,97 cm³/g ISO 534
Whiteness D65 99 % ISO 2470-2
CIE whiteness 125 % -
Gloss (Hunter) 50 % ISO 8254-1
Gloss (Lehmann) 50 % ISO 8254-2
Opacity 99,8 % ISO 8791-4

General information

The product data listed represent average values and describe the current quality status. They do not constitute a guarantee of specific properties for a specific application. Before using the product, we recommend carrying out suitable print and application tests. The paper should be stored at a constant temperature of 23 ± 5 °C and relative humidity of 50 ± 10 %.

Monomaterial foil

BluFilm 60

BluFilm 60

Product characteristics

  • Polypropylene film (PP) 60 µm
  • Bright white coated and with high opacity
  • Excellent printability with most ink systems incl. UV flexo
  • Back coating for very good adhesive anchorage
  • High rigidity for automatic label dispensing

Physical properties

Physical properties Typical value Unit Norm
Flächengewicht 45,4 g/m² spez. Test
Spezifisches Gewicht 22 m²/kg spez. Test
Dicke 60 µm spez. Test
Transparenz 20 % ASTM D1003
Glanz Oberseite (45°) 63 - ASTM D2457
Bruchlast MD / CD 100 / 195 MPa ASTM D882
Elastizitätsmodul MD / CD 1600 / 2600 MPa ASTM D882
Bruchdehnung MD / CD 170 / 170 % ASTM D882
Dimensionsstabilität -2 % spez. Test

General information

The product data listed represent average values and describe the current quality status. They do not constitute a guarantee of specific properties for a specific application. Before using the product, we recommend carrying out suitable print and application tests. The paper should be stored at a constant temperature of 23 ± 5 °C and relative humidity of 50 ± 10 %.

BluFilm 90

BluFilm 90

Produktcharakteristik

  • Polyethylenfolie mit hoher Dichte (HDPE) 110 µm
  • Beidseitig gestrichen und mit hoher Opazität
  • Exzellente Bedruckbarkeit mit herkömmlichen Druckverfahren sowie im Thermotransferdruck
  • Hervorragende Stanzbarkeit
  • Hohe Steifigkeit für automatische Etikettenspendung
  • Hohe Dimensionsstabilität und Resistenz gegen eine Vielzahl von Chemikalien

Physical properties

Physical properties Typical value Unit Norm
Flächengewicht 90 g/m² ISO 536
Dicke 110 µm DIN 53370
Dichte 0,8 g/cm³ -
Weiße 90 % ISO 2470
Opazität 94 % DIN 53146
Zugfestigkeit MD / CD 45 / 35 N/mm² ISO 527-3
Bruchdehnung MD / CD 120 / 130 % ISO 527-3
Weiterreißfestigkeit MD / CD 82 / 106 N/mm ASTM D1004-66
Biegesteifigkeit 0,27 mNm ISO 5629

General information

The product data listed represent average values and describe the current quality status. They do not constitute a guarantee of specific properties for a specific application. Before using the product, we recommend carrying out suitable print and application tests. The paper should be stored at a constant temperature of 23 ± 5 °C and relative humidity of 50 ± 10 %.

BluFilm Thermo TC Super

BluFilm Thermo TC Super

Produktcharakteristik

  • Basis (Substrat): Polypropylenfolie (PP) plus Thermoschicht
  • Druckbild: Schwarz
  • Sensibilität: Hoch
  • Druckgeschwindingkeit: Bis 250 mm/s, abhängig von Drucker und Einstellung
  • Schutzschicht: Ja, beidseitig: Topcoat und rückseitige Barriere
  • Haltbarkeit des Schriftbildes: 10 Jahre (s.u. "Allgemeine Hinweise")

Physikalische Eigenschaften

Physikalische Eigenschaften Wert Einheit Norm
Flächengewicht 85 ± 10 g/m² ISO 536
Dicke 105 ± 10 µm DIN 534
Glätte (Bekk), Thermoseite ≥ 1500 s ISO 5627
Weiße (D65), Thermoseite ≥ 85 % ISO 2470-2
Steifigkeit (Clark) längs 40 ± 10 mNm TAPPI T451
Steifigkeit (Clark) quer 60 ± 10 mNm TAPPI T451

Allgemeine Hinweise

Die o.a. Daten stellen typische Werte dar, entbinden den Verarbeiter jedoch nicht von eigenen Prüfungen. Hierzu empfehlen wir vor Verwendung des Produktes geeignete Druck- und Anwendungstests durchzuführen.

Thermopapiere sollten bei einer konstanten Temperatur von 23 ± 5 °C und einer relativen Luftfeuchtigkeit von 50 ± 10 % gelagert werden. Eine Lagerung von über 35 °C ist dringend zu vermeiden. Zudem darf die maximale relative Luftfeuchtigkeit 85 % nicht überschreiten. Starke Sonnen- oder Lichteinstrahlung sowie die Einwirkung von Chemikalien ist ebenso zu vermeiden.

Miscellaneous Monomaterial - Standard

BluCoat 80g

BluCoat 80g

Product characteristics

  • Silky matte coated woodfree paper
  • Semi-gloss
  • High whiteness
  • Suitable for high-quality advertising brochures, magazines and catalogs

Physical properties

Physical properties Typical value Unit Norm
Flächengewicht 80 g/m² ISO 536
Spezifisches Volumen (Bulk) 0,84 cm³/g ISO 534
Dicke 67 µm ISO 534
Rauhtiefe (Glätte) nach PPS 10 1,8 µm ISO 8791-4
Weiße (D65) 99 % ISO 2470-2
Glanz (Hunter) 42 % ISO 8254-1
Opazität 93 % ISO 2471

General information

The product data listed represent average values and describe the current quality status. They do not constitute a guarantee of specific properties for a specific application. Before using the product, we recommend carrying out suitable print and application tests. The paper should be stored at a constant temperature of 23 ± 5 °C and relative humidity of 50 ± 10 %.

BluCoat 90g

BluCoat 90g

Product characteristics

  • Silky matte coated woodfree paper
  • Semi-gloss
  • High whiteness
  • Suitable for high-quality advertising brochures, magazines and catalogs

Physical properties

Physical properties Typical value Unit Norm
Flächengewicht 90 g/m² ISO 536
Spezifisches Volumen (Bulk) 0,86 cm³/g ISO 534
Dicke 77 µm ISO 534
Rauhtiefe (Glätte) nach PPS 10 1,8 µm ISO 8791-4
Weiße (D65) 99 % ISO 2470-2
Glanz (Hunter) 42 % ISO 8254-1
Opazität 94 % ISO 2471

General information

The product data listed represent average values and describe the current quality status. They do not constitute a guarantee of specific properties for a specific application. Before using the product, we recommend carrying out suitable print and application tests. The paper should be stored at a constant temperature of 23 ± 5 °C and relative humidity of 50 ± 10 %.

Vellum D 58g

Vellum D 58g

Product characteristics

  • Woodfree paper for coating purpose
  • Satin and bright white
  • Suitable for all common printing processes
  • Can be used as coating base paper and for self-adhesive labels

Physikalische Eigenschaften

Physical properties Typical value Unit Norm
Flächengewicht 58 g/m² ISO 536
Dicke 60 µm ISO 534
Glätte (Bekk) - Oberseite 250 s ISO 5627
Glätte (Bekk) - Siebseite 250 s ISO 5627
Weiße (R 457) 100 % ISO 53145
Bruchlast MD / CD 3,3 / 2,0 kN/m ISO 1924-2
Weiterreißfestigkeit MD / CD 300 / 350 mN ISO 1974
Cobb, 30 Sek. Wasser - Oberseite 20 g/m² DIN EN 20535
Cobb, 30 Sek. Wasser - Siebseite 22 g/m² DIN EN 20535
Opazität 78 % DIN 53146

General information

The product data listed represent average values and describe the current quality status. They do not constitute a guarantee of specific properties for a specific application. Before using the product, we recommend carrying out suitable print and application tests. The paper should be stored at a constant temperature of 23 ± 5 °C and relative humidity of 50 ± 10 %.

Vellum D 85g

Vellum D 85g

Product characteristics

  • Woodfree satin paper
  • Suitable for all common printing processes
  • Can be used as coating base paper and for self-adhesive labels

Physical properties

Physical properties Typical value Unit Norm
Flächengewicht 85 g/m² ISO 536
Dicke 85 µm ISO 534
Glätte (Bekk) - Oberseite 180 s ISO 5627
Glätte (Bekk) - Siebseite 180 s ISO 5627
Weißgrad Oberseite (R 457) 103 % ISO 53145
Reißlänge längs / quer 5500 / 2500 m ISO 1924-2
Cobb, 30 Sek. Wasser - Oberseite 22 g/m² DIN EN 20535
Cobb, 30 Sek. Wasser - Siebseite 22 g/m² DIN EN 20535

General information

The product data listed represent average values and describe the current quality status. They do not constitute a guarantee of specific properties for a specific application. Before using the product, we recommend carrying out suitable print and application tests. The paper should be stored at a constant temperature of 23 ± 5 °C and relative humidity of 50 ± 10 %.

BluTherm T05 460

BluTherm T05 460

Product characteristics

  • Print image: Black
  • Sensitivity: high Standard
  • Printing speed: up to 300 mm/s, depending on printer settings
  • Typical applications: Bank statements, labels, lottery tickets, receipts, laminates
  • Lifetime of the typeface: 12 years (see "General information" below)

The product was manufactured without the use of phenols. However, it may contain traces of bisphenols (< 0.02 %) due to the production process.

Physical properties

Physical properties Typical value Unit Norm
Gewicht 72 ± 5 g/m² ISO 536
Dicke 80 ± 8 µm ISO 534
Glätte Thermoseite (Bekk) ≥ 200 s ISO 5627
Weiße (R457+) ≥ 88 % ISO 2470
Bruchlast längs / quer ≥ 4,7 / ≥ 2,2 kN/m ISO 1924-1
Weiterreißfestigkeit längs / quer ≥ 400 / ≥ 400 mN DIN 1974

Allgemeine Hinweise

Die o.a. Daten stellen typische Werte dar, entbinden den Verarbeiter jedoch nicht von eigenen Prüfungen. Hierzu empfehlen wir, vor Verwendung des Produktes geeignete Druck- und Anwendungstests durchzuführen.

Thermopapiere sollten bei einer konstanten Temperatur von 23 ± 5 °C und einer relativen Luftfeuchtigkeit von 50 ± 10 % gelagert werden. Eine Lagerung von über 35 °C ist dringend zu vermeiden. Zudem darf die maximale relative Luftfeuchtigkeit 85 % nicht überschreiten. Starke Sonnen- oder Lichteinstrahlung sowie die Einwirkung von Chemikalien ist ebenso zu vermeiden.

BluTherm TC 09 30

BluTherm TC 09 30

Product characteristics

  • Print image: Black
  • Sensitivity: Very high
  • Print speed: Up to 300 mm/s, depending on printer and setting
  • Protective layer: Yes: Topcoat
  • Lifetime of the typeface: 10 years (see below "General information")

The product was manufactured without the use of bisphenol A and S.

Physical properties

Physical properties Typical value Unit Norm
Flächengewicht 78 ± 5 g/m² ISO 536
Dicke 76 ± 6 µm ISO 534
Rauhigkeit (Parker Print PPS) ≤ 0,9 µm ISO 8791-4
Weiße (ohne UV) ≥ 83 % ISO 2470
Weiterreißfestigkeit längs (typischer Wert) 430 mN DIN 1974
Weiterreißfestigkeit quer (typischer Wert) 440 mN DIN 1974

Allgemeine Hinweise

Die o.a. Daten stellen typische Werte dar, entbinden den Verarbeiter jedoch nicht von eigenen Prüfungen. Hierzu empfehlen wir vor Verwendung des Produktes geeignete Druck- und Anwendungstests durchzuführen.

Thermopapiere sollten bei einer konstanten Temperatur von 23 ± 5 °C und einer relativen Luftfeuchtigkeit von 50 ± 10 % gelagert werden. Eine Lagerung von über 35 °C ist dringend zu vermeiden. Zudem darf die maximale relative Luftfeuchtigkeit 85 % nicht überschreiten. Starke Sonnen- oder Lichteinstrahlung sowie die Einwirkung von Chemikalien ist ebenso zu vermeiden.

Inquiry form for mono paper

The fields marked with an asterisk * are compulsory.

Wir sind der Partner für die Industrie und betreuen Kunden in Branchen wie Lebensmittel, Chemie, Automobil, Pharma, Textil und Logistik. Was dürfen wir für Sie tun? Lassen Sie sich von uns persönlich beraten.
